How to remove and install an air cleaner assembly on Ford Explorer Sport Trac?

Disconnect the cable from the negative terminal of the battery. Loosen the hose clamps on the air cleaner outlet tube assembly for 1994 and earlier models. Remove the tube from the throttle body and Air Filter Box. Cover the throttle body inlet to prevent foreign matter entry. Disconnect the vacuum lines at the bimetal sensor in the air cleaner cover. Disconnect the electrical connector at the Mass Air Flow (MAF) sensor. Remove the screws securing the air filter box assembly upper half. Label and disconnect the two small hoses from the upper case half and remove the upper half and air cleaner filter. Squeeze the protrusions on the air cleaner hot air tube and disconnect the tube from the air filter box. Remove the bolt securing the air cleaner intake tube assembly to the air cleaner intake deflector next to the radiator panel. Remove the intake tube from the lower half of the air filter box. Remove the screw securing the lower half of the air filter box to the mounting bracket. Remove the lower half of the air filter box. Installation is the reverse of removal. Tighten all hose clamps and fittings securely. For 1995 and later models, disconnect the IAT sensor and MAF sensor wiring. Remove the crankcase ventilation hose and retaining clamps from the air cleaner outlet tube. Detach the air outlet tube from the throttle body and MAF sensor. Disconnect the air filter box spring clips, then lift the upper half of the air filter box assembly from the vehicle. To remove the lower half (intake air duct) of the air filter box, carefully lift upward on the lower half to release the rubber grommets securing the housing to the fenderwell. Installation is the reverse of removal.

Genuine Ford Explorer Sport Trac Air Filter Box

Air Filter Housing

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

9 Air Filter Boxs found

View related parts
Ford Explorer Sport Trac Cleaner Assembly - Air
Part Number: 6L2Z-9A600-BA
$148.68 MSRP: $203.16
You Save: $54.48 (27%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Cleaner Assy - Air; Lower Cover, Lower Housing, Lower Tray
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2007-2010 Ford Explorer Sport Trac | 8 Cyl 4.6L | 5-Speed Automatic Transmission 5R55S, 6-Speed Automatic Transmission (6R80), 6-Speed Automatic Transmission 6R60, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Explorer Sport Trac Cleaner Assembly - Air
Part Number: 6L2Z-9A600-A
$79.46 MSRP: $110.39
You Save: $30.93 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cleaner Assy - Air; Lower Cover, Lower Housing
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2007-2010 Ford Explorer Sport Trac | 6 Cyl 4.0L SOHC EFI | 5-Speed Automatic Transmission 5R55S, 6-Speed Automatic Transmission (6R80), 6-Speed Automatic Transmission 6R60, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Explorer Sport Trac Cover
Part Number: 4L2Z-9661-AA
Product Specifications
- Other Name: Upper Cover, Upper Housing
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2007-2010 Ford Explorer Sport Trac | 6 Cyl 4.0L SOHC EFI | 5-Speed Automatic Transmission 5R55S, 6-Speed Automatic Transmission (6R80), 6-Speed Automatic Transmission 6R60, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Explorer Sport Trac Cover
Part Number: 6L2Z-9661-A
Product Specifications
- Replaced by: 6L2Z-9661-B
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2007-2010 Ford Explorer Sport Trac | 8 Cyl 4.6L | 5-Speed Automatic Transmission 5R55S, 6-Speed Automatic Transmission (6R80), 6-Speed Automatic Transmission 6R60, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Explorer Sport Trac Cleaner Assembly - Air
Part Number: 2L2Z-9600-AA
Product Specifications
- Other Name: Cleaner Assy - Air
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2001-2005 Ford Explorer Sport Trac | 6 Cyl 4.0L SOHC EFI | 5-Speed Automatic Transmission - 5R44E/5R55E, 5-Speed Manual Transmission - R1HD, Four-Wheel Drive, Left Hand Drive, Two-Wheel Drive
View related parts
Ford Explorer Sport Trac Cleaner Assembly - Air
Part Number: 6L2Z-9600-C
Product Specifications
- Other Name: Cleaner Assy - Air
- Replaced by: 7L2Z-9600-C
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2007 Ford Explorer Sport Trac | 6 Cyl 4.0L SOHC EFI | 5-Speed Automatic Transmission 5R55S, 6-Speed Automatic Transmission (6R80), 6-Speed Automatic Transmission 6R60, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Explorer Sport Trac Cleaner Assembly - Air
Part Number: 6L2Z-9600-D
Product Specifications
- Other Name: Cleaner Assy - Air; Air Cleaner Assembly
- Replaces: 6L2Z-9600-BA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2007-2010 Ford Explorer Sport Trac | 8 Cyl 4.6L | 5-Speed Automatic Transmission 5R55S, 6-Speed Automatic Transmission (6R80), 6-Speed Automatic Transmission 6R60, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Explorer Sport Trac Cleaner Assembly - Air
Part Number: 7L2Z-9600-C
Product Specifications
- Other Name: Cleaner Assy - Air; Air Cleaner Assembly
- Replaces: 6L2Z-9600-C
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2007-2010 Ford Explorer Sport Trac | 6 Cyl 4.0L SOHC EFI | 5-Speed Automatic Transmission 5R55S, 6-Speed Automatic Transmission (6R80), 6-Speed Automatic Transmission 6R60, Four-Wheel Drive (Full Time) (Left Hand Drive), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Explorer Sport Trac Cleaner Assembly - Air
Part Number: XL2Z-9600-AA
Product Specifications
- Other Name: Cleaner Assy - Air
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2001 Ford Explorer Sport Trac | 6 Cyl 4.0L SOHC EFI | 5-Speed Automatic Transmission - 5R44E/5R55E, 5-Speed Manual Transmission - R1HD, Four-Wheel Drive, Left Hand Drive, Two-Wheel Drive

Ford Explorer Sport Trac Air Filter Box

We provide a wide range of Ford Explorer Sport Trac Air Filter Box at the best prices possible. If you need Ford Explorer Sport Trac Air Filter Box, you can shop with confidence on our website. All our OEM parts come with a manufacturer's warranty and are delivered to your door step with a fast delivery service.

Ford Explorer Sport Trac Air Filter Box Parts Questions & Experts Answers

Cleaner Assembly - Air
2L2Z-9600-AA
Q: How to remove and install an air cleaner assembly on Ford Explorer Sport Trac?
A: Disconnect the cable from the negative terminal of the battery. Loosen the hose clamps on the air cleaner outlet tube assembly for 1994 and earlier models. Remove the tube from the Throttle Body and Air Filter Box. Cover the throttle body inlet to prevent foreign matter entry. Disconnect the vacuum lines at the bimetal sensor in the air cleaner cover. Disconnect the electrical connector at the Mass Air Flow (MAF) sensor. Remove the screws securing the air filter box assembly upper half. Label and disconnect the two small hoses from the upper case half and remove the upper half and air cleaner filter. Squeeze the protrusions on the air cleaner hot air tube and disconnect the tube from the air filter box. Remove the bolt securing the air cleaner intake tube assembly to the air cleaner intake deflector next to the radiator panel. Remove the intake tube from the lower half of the air filter box. Remove the screw securing the lower half of the air filter box to the mounting bracket. Remove the lower half of the air filter box. Installation is the reverse of removal. Tighten all hose clamps and fittings securely. For 1995 and later models, disconnect the IAT sensor and MAF sensor wiring. Remove the crankcase ventilation hose and retaining clamps from the air cleaner outlet tube. Detach the air outlet tube from the throttle body and MAF sensor. Disconnect the air filter box spring clips, then lift the upper half of the air filter box assembly from the vehicle. To remove the lower half (intake air duct) of the air filter box, carefully lift upward on the lower half to release the rubber grommets securing the housing to the fenderwell. Installation is the reverse of removal.
