How to remove and install the power steering fluid cooler on Ford Focus?

Unbolt and set aside the coolant recovery tank, then detach the power steering reservoir from its retaining bracket, disconnect the hose, and drain the fluid into a suitable container. Unclip the hose from the retaining bracket. Apply the parking brake, jack up the front of the vehicle, and support it on axle stands. Unscrew the securing screws from the splash shield under the radiator and remove the shield, disconnecting the temperature sensor electrical connector if installed. Remove the fluid cooler hose by inserting a special tool into the end of the hose along the pipe to release it, allowing the fluid to drain into the container. Unscrew the fluid cooler securing bolts and remove the cooler from the vehicle, noting that it is positioned across the front of the radiator. For installation, reverse the removal process and bleed the power steering hydraulic system.

Genuine Ford Focus Power Steering Cooler

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

5 Power Steering Coolers found

View related parts
Ford Focus Coil - Cooling
Part Number: 6S4Z-3D746-AA
$158.11 MSRP: $219.64
You Save: $61.53 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Hose & Tube Assembly, Power Steering Oil Cooler
- Replaces: 5S4Z-3D746-AA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2005-2006 Ford Focus | 4 Cyl 2.0L Duratec HE, 4 Cyl 2.3L | 4-Speed Automatic Transaxle - 4F27E, 5-Speed Manual Transmission - MTX75, Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Focus Coil - Cooling
Part Number: 3S4Z-3D746-BA
$170.28 MSRP: $236.55
You Save: $66.27 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Replaces: YS4Z-3D746-DA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2000-2004 Ford Focus | 4 Cyl 2.0L, 4 Cyl 2.0L CVH EFI, 4 Cyl 2.0L Zetec EFI, 4 Cyl 2.0L Zetec VVT | 4-Speed Automatic Transaxle - 4F27E, 4AT 4F27E, 5-Speed Manual Transmission - B5/IB5, 5-Speed Manual Transmission - MTX75, 5MT, 6-Speed Manual Transmission, 6MT, Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Focus Coil - Cooling
Part Number: 6S4Z-3D746-A
Product Specifications
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2006-2007 Ford Focus | 4 Cyl 2.0L Duratec HE, 4 Cyl 2.3L | 4-Speed Automatic Transaxle - 4F27E, 5-Speed Manual Transmission - MTX75, Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Focus Coil - Cooling
Part Number: 5S4Z-3D746-AA
Product Specifications
- Replaced by: 6S4Z-3D746-AA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2005 Ford Focus | 4 Cyl 2.0L Duratec HE, 4 Cyl 2.3L | 4-Speed Automatic Transaxle - 4F27E, 5-Speed Manual Transmission - MTX75, Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Focus Coil - Cooling
Part Number: YS4Z-3D746-DA
Product Specifications
- Replaced by: 3S4Z-3D746-BA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2000-2003 Ford Focus | 4 Cyl 2.0L | 4AT 4F27E, 5MT, 6MT

Ford Focus Power Steering Cooler

The Power Steering Cooler in Focus vehicles has the simple utility of helping in cooling the power steering fluid so as not to boil and subsequently damage its working parts. This cooler is usually fixed at the radiator support such that the air gets within the grille to cool the fluid. It works like a radiator by using fins and tubes to conduct the heat from the power steering fluid then transferring the heat to the flowing air. Generally, different types of Power Steering Coolers have been applied in the Ford Focus vehicles over the years and this makes it possible to have variations in the design and performance. Some of these include, Leakages, There may be instances where the cooler itself becomes a problem due to leaks, filthy fins, or become contaminated and this affects the power steering mechanism. Such situations require the use of a new Power Steering Cooler in order to correct the problems and bring the Ford Focus to a correct operation.

We provide a wide range of Ford Focus Power Steering Cooler at the best prices possible. If you need Ford Focus Power Steering Cooler, you can shop with confidence on our website. All our OEM parts come with a manufacturer's warranty and are delivered to your door step with a fast delivery service.

Ford Focus Power Steering Cooler Parts Questions & Experts Answers

Coil - Cooling
3S4Z-3D746-BA
Q: How to remove and install the power steering fluid cooler on Ford Focus?
A: Unbolt and set aside the coolant recovery tank, then detach the power steering reservoir from its retaining bracket, disconnect the hose, and drain the fluid into a suitable container. Unclip the hose from the retaining bracket. Apply the parking brake, jack up the front of the vehicle, and support it on axle stands. Unscrew the securing screws from the splash shield under the radiator and remove the shield, disconnecting the temperature sensor electrical connector if installed. Remove the fluid cooler hose by inserting a special tool into the end of the hose along the pipe to release it, allowing the fluid to drain into the container. Unscrew the fluid cooler securing bolts and remove the cooler from the vehicle, noting that it is positioned across the front of the radiator. For installation, reverse the removal process and bleed the power steering hydraulic system.
