How to remove and install a radiator and Coolant Reservoir on a Ford Expedition?

Disconnect the cable from the negative battery terminal. Drain the cooling system, then disconnect the lower hose from the coolant reservoir. Disconnect the overflow hose, then remove the bolts and pull the coolant reservoir straight up. Prior to installation make sure the coolant reservoir is clean and free of debris which could be drawn into the radiator. Installation is the reverse of removal. On 2007 and later models, have the refrigerant recovered before beginning this procedure. Remove the cooling fan and shroud assembly. On 2007 and later models, also remove the two end panels that are secured by pushpins. If equipped with an automatic transmission, detach the cooler lines from the radiator. Disconnect the upper and lower radiator hoses. Remove both headlight housings and, on 2008 and later models, remove the front bumper cover. Disconnect and plug the refrigerant lines at the condenser. Disconnect the horn wiring at the side of the radiator and remove the horns. Remove the bolts on the sides of the radiator. Push the radiator assembly toward the engine and push on the two lower condenser-to-radiator clips until the radiator is separated from the condenser. On earlier models, remove the mounting bolts and take off the two upper radiator mounts and the mounts that hold the lug wrench and jack handle. On all models, carefully lift the radiator out of the vehicle. Prior to installation of the radiator, replace any damaged hose clamps and radiator hoses. Radiator installation is the reverse of removal. When installing the radiator on earlier models, make sure it seats properly in the lower saddles and that the rubber mounts are intact. After installation, fill the system with the proper mixture of antifreeze, and also check the automatic transmission fluid level.

Genuine Ford Expedition Coolant Reservoir

Coolant Tank Reservoir

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

7 Coolant Reservoirs found

View related parts
Ford Expedition Tank Assembly - Radiator Overflow
Part Number: FL3Z-8A080-A
$103.69 MSRP: $106.42
You Save: $2.73 (3%)
ADD TO CART
Product Specifications
- Other Name: Tank Assy - Radiator Overflow; Expansion Tank, Reservoir
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2018-2024 Ford Expedition | 6 Cyl 3.5 L FLEX, 6 Cyl 3.5 L GAS, 6 Cyl 3.5L GTDI | 10-Speed Automatic Transmission (10R80), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Expedition Tank Assembly - Radiator Overflow
Part Number: BL3Z-8A080-B
$183.28 MSRP: $277.70
You Save: $94.42 (34%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Tank Assy - Radiator Overflow; Expansion Tank, Lower Housing, Lower Tray
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2015-2017 Ford Expedition | 6 Cyl 3.5L GTDI | 4AT 4R75W, 4-Speed Automatic Transmission 4R70W (AODE), 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 6-Speed Automatic Transmission (6R75), 6-Speed Automatic Transmission (6R80), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Expedition Tank Assembly - Radiator Overflow
Part Number: AL1Z-8A080-A
$153.99 MSRP: $225.13
You Save: $71.14 (32%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Tank Assy - Radiator Overflow; Expansion Tank, Lower Tray
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2010-2014 Ford Expedition | 8 Cyl 5.4L | 4AT 4R75W, 4-Speed Automatic Transmission 4R70W (AODE), 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 6-Speed Automatic Transmission (6R75), 6-Speed Automatic Transmission (6R80), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Expedition Tank Assembly - Radiator Overflow
Part Number: 9L3Z-8A080-A
$99.35 MSRP: $145.25
You Save: $45.90 (32%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Tank Assy - Radiator Overflow; Expansion Tank, Lower Housing, Lower Tray
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2009-2010 Ford Expedition | 8 Cyl 5.4L | 4AT 4R75W, 4-Speed Automatic Transmission 4R70W (AODE), 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 6-Speed Automatic Transmission (6R75), 6-Speed Automatic Transmission (6R80), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Expedition Tank Assembly - Radiator Overflow
Part Number: 5L3Z-8A080-AA
$107.25 MSRP: $156.80
You Save: $49.55 (32%)
ADD TO CART
Product Specifications
- Other Name: Tank Assy - Radiator Overflow; Expansion Tank, Reservoir
- Replaces: 3L1Z-8A080-AA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2003-2006 Ford Expedition | 8 Cyl 4.6L Romeo SOHC EFI, 8 Cyl 5.4L, 8 Cyl 5.4L Modular SOHC | 4-Speed Automatic Transmission 4R70W (AODE), 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 4AT 4R75W, 6-Speed Automatic Transmission (6R75), 6-Speed Automatic Transmission (6R80), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Expedition Tank Assembly - Radiator Overflow
Part Number: 3L1Z-8A080-AA
$107.25 MSRP: $156.80
You Save: $49.55 (32%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Tank Assy - Radiator Overflow
- Replaced by: 5L3Z-8A080-AA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2003-2004 Ford Expedition | 8 Cyl 4.6L Romeo SOHC EFI, 8 Cyl 5.4L Modular SOHC | 4AT 4R75W, 4-Speed Automatic Transmission 4R70W (AODE), 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 6-Speed Automatic Transmission (6R75), 6-Speed Automatic Transmission (6R80), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Expedition Tank Assembly - Radiator
Part Number: 7L1Z-8A080-A
$239.59 MSRP: $356.53
You Save: $116.94 (33%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Tank Assy - Radiator Overflow
- Replaced by: AL1Z-8A080-B
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2007-2008 Ford Expedition | 8 Cyl 5.4L | 4AT 4R75W, 4-Speed Automatic Transmission 4R70W (AODE), 4-Speed Automatic Transmission 4R75E Livonia, 4-Speed Automatic Transmission AODEW/4R75E W/TSS, 6-Speed Automatic Transmission (6R75), 6-Speed Automatic Transmission (6R80), Four-Wheel Drive (Part Time) (Left Hand Drive), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)

Ford Expedition Coolant Reservoir

The Coolant Reservoir that is installed on the Ford Expedition car models is a part of the cooling system of the car, which solves the tasks of preventing a loss of coolant into the roadway and the complete absence of air inside the system. It is used to exclude presence of air that causes rust and corrosion of the cooling system parts and also keeps dangers of leakage of anti-freeze fluid in check. There are two main types of Coolant Reservoirs used in Expedition vehicles: over flow type tank systems and expansion tank systems and the two are fundamentally different concepts despite the fact that they are used in controlling coolant levels and pressure. It is advised that reservoirs be routinely inspected for defects in the body, leaking, and corrosion due to age and thermal expansion/contraction, and coolant fouling that may obscure accurate determination of coolant levels.

We provide a wide range of Ford Expedition Coolant Reservoir at the best prices possible. If you need Ford Expedition Coolant Reservoir, you can shop with confidence on our website. All our OEM parts come with a manufacturer's warranty and are delivered to your door step with a fast delivery service.

Ford Expedition Coolant Reservoir Parts Questions & Experts Answers

Tank Assembly - Radiator Overflow
3L1Z-8A080-AA
Q: How to remove and install a radiator and Coolant Reservoir on a Ford Expedition?
A: Disconnect the cable from the negative battery terminal. Drain the cooling system, then disconnect the lower hose from the coolant reservoir. Disconnect the overflow hose, then remove the bolts and pull the coolant reservoir straight up. Prior to installation make sure the coolant reservoir is clean and free of debris which could be drawn into the radiator. Installation is the reverse of removal. On 2007 and later models, have the refrigerant recovered before beginning this procedure. Remove the cooling fan and shroud assembly. On 2007 and later models, also remove the two end panels that are secured by pushpins. If equipped with an automatic transmission, detach the cooler lines from the radiator. Disconnect the upper and lower radiator hoses. Remove both headlight housings and, on 2008 and later models, remove the front bumper cover. Disconnect and plug the refrigerant lines at the condenser. Disconnect the horn wiring at the side of the radiator and remove the horns. Remove the bolts on the sides of the radiator. Push the radiator assembly toward the engine and push on the two lower condenser-to-radiator clips until the radiator is separated from the condenser. On earlier models, remove the mounting bolts and take off the two upper radiator mounts and the mounts that hold the lug wrench and jack handle. On all models, carefully lift the radiator out of the vehicle. Prior to installation of the radiator, replace any damaged hose clamps and radiator hoses. Radiator installation is the reverse of removal. When installing the radiator on earlier models, make sure it seats properly in the lower saddles and that the rubber mounts are intact. After installation, fill the system with the proper mixture of antifreeze, and also check the automatic transmission fluid level.
