How should you carefully remove the instrument panel and its components on Ford Fusion?

During the removal of the instrument panel, make careful notes of how each piece comes off, where it fits in relation to other pieces, and what holds it in place. Noting how each part is installed before removal will make reassembly much easier. Begin by removing the steering wheel, all dashboard trim panels and the glove box, air conditioning and heater control assembly, instrument cluster and radio, carpeting and carpet pad from the front of the vehicle, door weatherstripping from both sides, right lower instrument panel insulator (for 2010 and later models), front seats (removing both front seats is not absolutely necessary but allows more room to work and prevents potential damage), and the center console. Carefully remove the left and right A-pillar trim panels by prying them off. Grasp each front door opening weather strip/sill panel/kick panels and pull them off. Disconnect the two electrical connectors in the left kick panel area and the bulkhead electrical connector and antenna cable in the right kick panel area. For 2010 and later models, disconnect the satellite antenna if equipped. Disconnect the small gray and black electrical connectors from the Smart Junction Box located under the left end of the dash. In the glove box area, disconnect all air conditioning system electrical connectors. Disconnect all electrical connectors and wiring harness clips located on the floor between the two front seats, as well as any other connectors that connect wiring between the vehicle and the instrument panel. For 2010 and later models, remove the two nuts that secure the steering column pinch bolt cover and set the cover aside. Mark the relationship of the upper steering column shaft to the lower shaft, remove the steering column pinch-bolt, and separate the upper column shaft from the lower shaft. Discard the old pinch bolt and install a new one during reassembly. Remove the two hood release handle screws and set the handle aside. Disconnect the in-vehicle temperature sensor aspirator hose from the heater core and evaporator core housing by separating the aspirator hose retaining clips and pulling the hose away. Remove the two bolts in the instrument cluster opening, followed by the two or three bolts from the instrument panel center brace depending on the model year. Remove the bolts from the left and right lower corners of the instrument panel, as well as the three instrument panel end bolts, ensuring an assistant supports the instrument panel to avoid damage. With assistance, remove the instrument panel from the vehicle. Installation is the reverse of removal, but ensure to remove the trim panel clips from the A-pillars before installing the A-pillar trim panels, adjusting the gap between each clip mounting screw and the clip for a tight fit in the mounting bracket.

Genuine Ford Fusion Instrument Cluster

Speedometer Instrument Cluster

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

207 Instrument Clusters found

View related parts
Ford Fusion Instrument Cluster
Part Number: 6H6Z-10849-AA
$334.63 MSRP: $447.02
You Save: $112.39 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2006-2007 Ford Fusion | 4 Cyl 2.3L, 6 Cyl 3.0L DOHC EFI, 6 Cyl 3.5L DOHC VCT SMPI | 5-Speed Automatic Transmission Mazda FNR5, 5-Speed Manual Transmission (G5M), 6-Speed Automatic Transaxle - AWF21, 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Manual Transmission Mazda G6M, CVT Auto Trans Powersplit Elec, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: BE5Z-10849-GB
$339.37 MSRP: $453.46
You Save: $114.09 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2011-2012 Ford Fusion | 6 Cyl 3.0L OHC Duratec, 6 Cyl 3.5L DOHC VCT SMPI | 5-Speed Automatic Transmission Mazda FNR5, 5-Speed Manual Transmission (G5M), 6-Speed Automatic Transaxle - AWF21, 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Manual Transmission Mazda G6M, CVT Auto Trans Powersplit Elec, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: BE5Z-10849-FB
$321.34 MSRP: $428.92
You Save: $107.58 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Replaced by: BE5Z-10849-FC
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2011-2012 Ford Fusion | 4 Cyl 2.5L Duratec HE PFI | 6-Speed Manual Transmission Mazda G6M, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: BE5Z-10849-JB
$328.53 MSRP: $438.71
You Save: $110.18 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Replaced by: BE5Z-10849-JC
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2011-2012 Ford Fusion | 4 Cyl 2.5L Duratec HE PFI | 6-Speed Automatic Transmission 6F Mid-Range, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: AE5Z-10849-RB
$337.55 MSRP: $450.98
You Save: $113.43 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Replaced by: AE5Z-10849-RC
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2010 Ford Fusion | 6 Cyl 3.0L OHC Duratec, 6 Cyl 3.5L DOHC VCT SMPI | 5-Speed Automatic Transmission Mazda FNR5, 5-Speed Manual Transmission (G5M), 6-Speed Automatic Transaxle - AWF21, 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Manual Transmission Mazda G6M, CVT Auto Trans Powersplit Elec, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: 8H6Z-10849-A
$343.86 MSRP: $459.58
You Save: $115.72 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2008-2009 Ford Fusion | 4 Cyl 2.3L, 6 Cyl 3.0L DOHC EFI, 6 Cyl 3.5L DOHC VCT SMPI | 5-Speed Automatic Transmission Mazda FNR5, 5-Speed Manual Transmission (G5M), 6-Speed Automatic Transaxle - AWF21, 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Manual Transmission Mazda G6M, CVT Auto Trans Powersplit Elec, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: 7E5Z-10849-B
$361.06 MSRP: $483.00
You Save: $121.94 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2007 Ford Fusion | 4 Cyl 2.3L, 6 Cyl 3.0L DOHC EFI, 6 Cyl 3.5L DOHC VCT SMPI | 5-Speed Automatic Transmission Mazda FNR5, 5-Speed Manual Transmission (G5M), 6-Speed Automatic Transaxle - AWF21, 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Manual Transmission Mazda G6M, CVT Auto Trans Powersplit Elec, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion INSTRUMENT CLUSTER
Part Number: LS7Z-10849-JA
$475.42 MSRP: $638.69
You Save: $163.27 (26%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2020 Ford Fusion | 4 Cyl 2.0 L FULL HYBRID EV-GAS (FHEV), 4 Cyl 2.0 L PLUG-IN HYBRID EV-GAS (PHEV)
View related parts
Ford Fusion Instrument Cluster
Part Number: HS7Z-10849-JF
$485.19 MSRP: $652.00
You Save: $166.81 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2017 Ford Fusion | 4 Cyl 2.0L Duratec Hybrid (130kW) | 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F55, 6-Speed Manual Transmission - B6, ECVT Auto Trans Power Split, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: ES7Z-10849-JA
$502.56 MSRP: $675.65
You Save: $173.09 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2014 Ford Fusion | 4 Cyl 1.5L GTDI, 4 Cyl 2.0L EcoBoost (240PS) , 4 Cyl 2.5L Duratec (110kW/150PS) | 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F55, 6-Speed Manual Transmission - B6, ECVT Auto Trans Power Split, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: BE5Z-10849-CB
$338.36 MSRP: $452.09
You Save: $113.73 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Replaced by: BE5Z-10849-CC
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2011-2012 Ford Fusion | 4 Cyl 2.5L Duratec HE PFI | 6-Speed Automatic Transmission 6F Mid-Range, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: BH6Z-10849-CA
$674.22 MSRP: $917.48
You Save: $243.26 (27%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2011 Ford Fusion | 4 Cyl 2.5L PFI Gas/Electric | 5-Speed Automatic Transmission Mazda FNR5, 5-Speed Manual Transmission (G5M), 6-Speed Automatic Transaxle - AWF21, 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Manual Transmission Mazda G6M, CVT Auto Trans Powersplit Elec, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: 8E5Z-10849-C
$312.85 MSRP: $417.35
You Save: $104.50 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2008-2009 Ford Fusion | 4 Cyl 2.3L, 6 Cyl 3.0L DOHC EFI, 6 Cyl 3.5L DOHC VCT SMPI | 5-Speed Automatic Transmission Mazda FNR5, 5-Speed Manual Transmission (G5M), 6-Speed Automatic Transaxle - AWF21, 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Manual Transmission Mazda G6M, CVT Auto Trans Powersplit Elec, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: ES7Z-10849-AA
$336.12 MSRP: $449.05
You Save: $112.93 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2014-2015 Ford Fusion | 4 Cyl 2.5L Duratec (110kW/150PS) | 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F55, 6-Speed Manual Transmission - B6, ECVT Auto Trans Power Split, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: FS7Z-10849-AA
$336.12 MSRP: $449.05
You Save: $112.93 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2015 Ford Fusion | 4 Cyl 2.5L Duratec (110kW/150PS) | 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Automatic Transmission 6F55, 6-Speed Manual Transmission - B6, ECVT Auto Trans Power Split, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: BE5Z-10849-EB
$337.23 MSRP: $450.55
You Save: $113.32 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Replaced by: BE5Z-10849-EC
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2011-2012 Ford Fusion | 4 Cyl 2.5L Duratec HE PFI | 6-Speed Manual Transmission Mazda G6M, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: 9E5Z-10849-B
$340.50 MSRP: $455.00
You Save: $114.50 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2009 Ford Fusion | 4 Cyl 2.3L, 6 Cyl 3.0L DOHC EFI, 6 Cyl 3.5L DOHC VCT SMPI | 5-Speed Automatic Transmission Mazda FNR5, 5-Speed Manual Transmission (G5M), 6-Speed Automatic Transaxle - AWF21, 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Manual Transmission Mazda G6M, CVT Auto Trans Powersplit Elec, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: BH6Z-10849-AB
$325.51 MSRP: $434.60
You Save: $109.09 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Replaced by: BH6Z-10849-AC
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2011-2012 Ford Fusion | 6 Cyl 3.5L DOHC VCT SMPI | 5-Speed Automatic Transmission Mazda FNR5, 5-Speed Manual Transmission (G5M), 6-Speed Automatic Transaxle - AWF21, 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Manual Transmission Mazda G6M, CVT Auto Trans Powersplit Elec, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: ES7Z-10849-CA
$348.78 MSRP: $466.28
You Save: $117.50 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2014-2015 Ford Fusion | 4 Cyl 1.6L PI TC ETHNL | 6-Speed Manual Transmission - B6, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive
View related parts
Ford Fusion Instrument Cluster
Part Number: AH6Z-10849-AB
$350.74 MSRP: $468.94
You Save: $118.20 (26%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Cluster Assembly
- Replaced by: AH6Z-10849-AC
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2010 Ford Fusion | 4 Cyl 2.5L Duratec HE PFI, 4 Cyl 2.5L PFI Gas/Electric, 6 Cyl 3.0L OHC Duratec, 6 Cyl 3.5L DOHC VCT SMPI | 5-Speed Automatic Transmission Mazda FNR5, 5-Speed Manual Transmission (G5M), 6-Speed Automatic Transaxle - AWF21, 6-Speed Automatic Transmission 6F Mid-Range, 6-Speed Manual Transmission Mazda G6M, CVT Auto Trans Powersplit Elec, Four-Wheel Drive (Full Time) (Left Hand Drive), Front-Wheel Drive (Left Hand Drive), Left Hand Drive

| Page 1 of 11 |Next >

1-20 of 207 Results

Ford Fusion Instrument Cluster

The Instrument Cluster is the real parts in the Ford Fusion vehicle situated behind the steering wheel that is mainly for offering the required drive information. Many of them are the basic measurement tools like the speedometer, tachometer, and fuel gauge plus a number of warning lights providing the driver with information on the vehicle and engine performance, seat belt and air bag status, among others. The Ford Fusion over the years has adopted various styles of the Instrument Clusters, this is due to the changing technology and trends. Analog gauges have always used conventional methods with the newer models possibly using touch screen or digital methods to add functionality and interactivity. The major difference between these styles is found in the application of extras like real time data and flexible display that enhance the driving experience of cars made by Ford Fusion. It is significant to keep the Instrument Cluster in good working condition to be able to provide the correct readings that can help out during the trips.

We provide a wide range of Ford Fusion Instrument Cluster at the best prices possible. If you need Ford Fusion Instrument Cluster, you can shop with confidence on our website. All our OEM parts come with a manufacturer's warranty and are delivered to your door step with a fast delivery service.

Ford Fusion Instrument Cluster Parts Questions & Experts Answers

Instrument Cluster
6E5Z-10849-AA
Q: How should you carefully remove the instrument panel and its components on Ford Fusion?
A: During the removal of the instrument panel, make careful notes of how each piece comes off, where it fits in relation to other pieces, and what holds it in place. Noting how each part is installed before removal will make reassembly much easier. Begin by removing the steering wheel, all dashboard trim panels and the glove box, air conditioning and heater control assembly, instrument cluster and radio, carpeting and carpet pad from the front of the vehicle, door weatherstripping from both sides, right lower instrument panel insulator (for 2010 and later models), front seats (removing both front seats is not absolutely necessary but allows more room to work and prevents potential damage), and the center console. Carefully remove the left and right A-pillar trim panels by prying them off. Grasp each front door opening weather strip/sill panel/kick panels and pull them off. Disconnect the two electrical connectors in the left kick panel area and the bulkhead electrical connector and antenna cable in the right kick panel area. For 2010 and later models, disconnect the satellite antenna if equipped. Disconnect the small gray and black electrical connectors from the Smart Junction Box located under the left end of the dash. In the glove box area, disconnect all air conditioning system electrical connectors. Disconnect all electrical connectors and wiring harness clips located on the floor between the two front seats, as well as any other connectors that connect wiring between the vehicle and the instrument panel. For 2010 and later models, remove the two nuts that secure the steering column pinch bolt cover and set the cover aside. Mark the relationship of the upper steering column shaft to the lower shaft, remove the steering column pinch-bolt, and separate the upper column shaft from the lower shaft. Discard the old pinch bolt and install a new one during reassembly. Remove the two hood release handle screws and set the handle aside. Disconnect the in-vehicle temperature sensor aspirator hose from the heater core and evaporator core housing by separating the aspirator hose retaining clips and pulling the hose away. Remove the two bolts in the instrument cluster opening, followed by the two or three bolts from the instrument panel center brace depending on the model year. Remove the bolts from the left and right lower corners of the instrument panel, as well as the three instrument panel end bolts, ensuring an assistant supports the instrument panel to avoid damage. With assistance, remove the instrument panel from the vehicle. Installation is the reverse of removal, but ensure to remove the trim panel clips from the A-pillars before installing the A-pillar trim panels, adjusting the gap between each clip mounting screw and the clip for a tight fit in the mounting bracket.
