How to drain and replace transmission fluid and Filter on Ford Thunderbird?

At the specified intervals, the transmission fluid should be drained and replaced. This should only be done after the engine has cooled down completely as the fluid will remain hot long after driving. Before starting, purchase the recommended transmission fluid, a new filter and gaskets. Never reuse the old filter or gasket. You will also need jack stands to support the vehicle, a drain pan capable of holding at least eight quarts, newspapers and clean rags. Raise the vehicle and support it securely on jack stands. With the drain pan in place, remove the front and side transmission pan mounting bolts. Loosen the rear pan bolts approximately four turns. Carefully pry the transmission pan loose with a screwdriver, allowing the fluid to drain. Be careful not to damage the pan or transmission gasket surfaces to avoid leaks. Remove the remaining bolts, pan and gasket. Clean the gasket surface of the transmission to remove all traces of the old gasket and sealant. Drain the fluid from the transmission pan, clean it with solvent and dry it with compressed air. Remove the filter from the mount inside the transmission. Install a new seal, gasket and filter. Tighten the mounting bolts securely. Ensure the gasket surface on the transmission pan is clean, then install a new gasket. Put the pan in place against the transmission and install the bolts. Tighten each bolt a little at a time until the final torque figure is reached. Be careful not to over tighten the bolts. Lower the vehicle and add about four or five pints of automatic transmission fluid through the filler tube. With the transmission in Park and the parking brake set, run the engine at a fast idle, but don't race it. Move the gear selector through each range and back to Park. Check the fluid level and add fluid if needed to reach the correct level. Check under the vehicle for leaks during the first few trips.

Genuine Ford Thunderbird Automatic Transmission Filter

AT Filter

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

10 Automatic Transmission Filters found

View related parts
Ford Thunderbird Kit - Transm. Fluid
Part Number: 2W4Z-7B155-D
$60.85 MSRP: $120.91
You Save: $60.06 (50%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Kit - Transm. Fluid External Filter
- Replaced by: 2W4Z-7B155-F
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2005 Ford Thunderbird | 8 Cyl 3.9L DOHC EFI NA | 5-Speed Automatic Transmission 5R55S, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Thunderbird Filter Assembly
Part Number: F6AZ-7A098-A
$33.86 MSRP: $54.00
You Save: $20.14 (38%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Filter Assy; Filter, Screen
- Replaces: F4TZ-7A098-A
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1996-1997 Ford Thunderbird | 6 Cyl 3.8L, 8 Cyl 4.6L | 4AT 4R70W
View related parts
Ford Thunderbird Screen Assembly
Part Number: 3W4Z-7A098-AA
$37.85 MSRP: $60.36
You Save: $22.51 (38%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Screen Assy; Filter
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2003-2005 Ford Thunderbird | 8 Cyl 3.9L DOHC EFI NA | 5-Speed Automatic Transmission 5R55S, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Thunderbird Filter Assembly - Oil
Part Number: 2W4Z-7B155-E
$31.58 MSRP: $50.36
You Save: $18.78 (38%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Filter Assy - Oil
- Replaced by: 2W4Z-7B155-G
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2005 Ford Thunderbird | 8 Cyl 3.9L DOHC EFI NA | 5-Speed Automatic Transmission 5R55S, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Thunderbird Screen Assembly
Part Number: F2VY-7A098-A
$17.78 MSRP: $28.36
You Save: $10.58 (38%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Screen Assy; Filter
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1994-1995 Ford Thunderbird | 6 Cyl 3.8L, 8 Cyl 4.6L | 4AT 4R70W
View related parts
Ford Thunderbird Filter Assembly - Oil
Part Number: 2W4Z-7B155-BA
$31.58 MSRP: $50.36
You Save: $18.78 (38%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Filter Assy - Oil
- Replaced by: 2W4Z-7B155-G
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2002-2005 Ford Thunderbird | 8 Cyl 3.9L DOHC EFI NA | 5-Speed Automatic Transmission 5R55S, 5-Speed Automatic Transmission NAAO 5R55N, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Thunderbird Filter Assembly - Oil
Part Number: 2W4Z-7B155-CA
$60.85 MSRP: $120.91
You Save: $60.06 (50%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Filter Assy - Oil
- Replaced by: 2W4Z-7B155-F
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2004-2005 Ford Thunderbird | 8 Cyl 3.9L DOHC EFI NA | 5-Speed Automatic Transmission 5R55S, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Thunderbird Screen Assembly
Part Number: XW4Z-7A098-BB
$21.57 MSRP: $29.47
You Save: $7.90 (27%)
ADD TO CART
Product Specifications
- Other Name: Screen Assy; Filter
- Replaces: XW4Z-7A098-BA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2002 Ford Thunderbird | 8 Cyl 3.9L DOHC EFI NA | 5-Speed Automatic Transmission NAAO 5R55N, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Thunderbird Screen Assembly
Part Number: E1AZ-7A098-A
Product Specifications
- Other Name: Screen Assy; Filter, Filter Kit
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1980-1993 Ford Thunderbird | 4 Cyl 2.3L, 6 Cyl 3.3L, 6 Cyl 3.8L, 8 Cyl 4.2L, 8 Cyl 5.0L | 3AT C3, 3AT C4, 3AT C5, 4AT A4LD, 4AT AOD
View related parts
Ford Thunderbird Screen Assembly
Part Number: E6TZ7A098B
Product Specifications
- Other Name: Screen Assy; Filter
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1987-1988 Ford Thunderbird | 4 Cyl 2.3L, 6 Cyl 3.8L, 8 Cyl 5.0L | 4AT A4LD, 4AT AOD

Ford Thunderbird Automatic Transmission Filter

Automatic Transmission Filter found in Ford Thunderbird vehicles helps to keep the condition of the transmission system good by filtering out the pointless dirt from the transmission fluid. This filter guarantees that the fluid is free from contaminant and this is paramount for the lubrication and cooling system of the transmission. Several Automatic Transmission Filters have been used in Ford Thunderbird over the years, including; The most frequent type is embedded within the transmission and it is accessed through the removal of the fluid pan which can be removed and replaced during servicing. However, there are some cases when filters are hidden and they often come with names like 'lifetime filters', which cannot be easily replaced. Its possible to have external types of spin-on or cartridge type filters depending on the application so that the filters may be more accessible for changes much more than the engines. Extra performance transmission filters are also supplied that increased level of filtration and improved the rate of the fluid flow resulting in better overall rate of the transmission.

We provide a wide range of Ford Thunderbird Automatic Transmission Filter at the best prices possible. If you need Ford Thunderbird Automatic Transmission Filter, you can shop with confidence on our website. All our OEM parts come with a manufacturer's warranty and are delivered to your door step with a fast delivery service.

Ford Thunderbird Automatic Transmission Filter Parts Questions & Experts Answers

Screen Assembly
E1AZ-7A098-A
Q: How to drain and replace transmission fluid and Filter on Ford Thunderbird?
A: At the specified intervals, the transmission fluid should be drained and replaced. This should only be done after the engine has cooled down completely as the fluid will remain hot long after driving. Before starting, purchase the recommended transmission fluid, a new filter and gaskets. Never reuse the old filter or gasket. You will also need jack stands to support the vehicle, a drain pan capable of holding at least eight quarts, newspapers and clean rags. Raise the vehicle and support it securely on jack stands. With the drain pan in place, remove the front and side transmission pan mounting bolts. Loosen the rear pan bolts approximately four turns. Carefully pry the transmission pan loose with a screwdriver, allowing the fluid to drain. Be careful not to damage the pan or transmission gasket surfaces to avoid leaks. Remove the remaining bolts, pan and gasket. Clean the gasket surface of the transmission to remove all traces of the old gasket and sealant. Drain the fluid from the transmission pan, clean it with solvent and dry it with compressed air. Remove the filter from the mount inside the transmission. Install a new seal, gasket and filter. Tighten the mounting bolts securely. Ensure the gasket surface on the transmission pan is clean, then install a new gasket. Put the pan in place against the transmission and install the bolts. Tighten each bolt a little at a time until the final torque figure is reached. Be careful not to over tighten the bolts. Lower the vehicle and add about four or five pints of automatic transmission fluid through the filler tube. With the transmission in Park and the parking brake set, run the engine at a fast idle, but don't race it. Move the gear selector through each range and back to Park. Check the fluid level and add fluid if needed to reach the correct level. Check under the vehicle for leaks during the first few trips.
