2 diagrams found for the vehicle you selected.Select your vehicle options to narrow down results.
  • 1.Electrical Components (Fuse And Relays)
    2021 Ford Ranger Fuel Supply Diagram 1
  • 2.Fuel System Components
    2021 Ford Ranger Fuel Supply Diagram 2
Sort by:
Ref No.
Ref No.
Part No. & Part Description
Price & Qty.
Part No. &
Part Description
  • 4
    DG9Z-14526-M
    Fuse
    • Part Notes: Fuse And Relays, 2 Blade-30 Amp
    $1.27 $0.82
    10
    Add To Cart
  • 4 Ford DG9Z-14526-F
    DG9Z-14526-F
    Fuse
    • Part Notes: Fuse And Relays, 2 Blade-5 Amp
    $1.27 $0.82
    10
    Add To Cart
  • 4 Ford DG9Z-14526-G
    DG9Z-14526-G
    Fuse
    • Part Notes: Fuse And Relays, 2 Blade-7.5 Amp
    $1.27 $0.82
    10
    Add To Cart
  • 4 Ford DG9Z-14526-H
    DG9Z-14526-H
    Fuse
    • Part Notes: Fuse And Relays, 2 Blade-10 Amp
    $1.28 $0.82
    10
    Add To Cart
  • 4 Ford DG9Z-14526-J
    DG9Z-14526-J
    Fuse
    • Part Notes: Fuse And Relays, 2 Blade-15 Amp
    $1.27 $0.82
    10
    Add To Cart
  • 4
    DG9Z-14526-K
    Fuse
    • Part Notes: Fuse And Relays, 2 Blade-20 Amp
    $1.98 $1.28
    10
    Add To Cart
  • 5
    DG9Z-14526-P
    Fuse
    • Part Notes: Fuse And Relays, 3 Blade-10 Amp
    $2.55 $1.64
    10
    Add To Cart
  • 5 Ford DG9Z-14526-N
    DG9Z-14526-N
    Fuse
    • Part Notes: Fuse And Relays, 3 Blade-5 Amp
    $2.55 $1.64
    10
    Add To Cart
  • 5 Ford DG9Z-14526-S
    DG9Z-14526-S
    Fuse
    • Part Notes: Fuse And Relays, 3 Blade-7.5 Amp
    $2.55 $1.64
    10
    Add To Cart
  • 8
    GU5Z-14N089-A
    Relay
    • Part Notes: Fuse And Relays, 40 Amp-4 Terminal
    $38.00 $29.21
    1
    Add To Cart
  • 9 Ford GU5Z-14N089-B
    GU5Z-14N089-B
    Relay
    • Part Notes: Fuse And Relays, 40 Amp-5 Terminal
    $59.83 $45.99
    1
    Add To Cart
Genuine Ford Parts, the Right Choice
FordPartsGiant.com offers the wholesale prices for genuine 2021 Ford Ranger parts. Parts like Fuel Supply are shipped directly from authorized Ford dealers and backed by the manufacturer's warranty. Parts fit for the following vehicle options. Engine: 4 Cyl 2.3 L GAS.
