How to replace the CKP sensor on Ford Mustang?

A CKP sensor for the 3.7L V6 engine is situated at the rear of the engine block at an opening on the side of the engine. First, remove the cable involving the negative terminal of the battery, then follow the correct procedure that is the raising of the automobile off the ground with the aid of jacks and placement of jackstands. Remove heat shield fasteners; heat shield then rubber grommet/plug from the left side of the engine block. Open the access hole to quickly unplug the electrical connector from CKP sensor, and then the center bolt can be removed to take the sensor out of the rear oil seal retainer. Coat the O-ring for the sensor with the clean engine oil, insert the sensor to the seal retainer until it is hidden and lock it with the mounting bolt. For the 4.0L V6 engine, the CKP sensor is installed on the front side of the timing chain cover . Remove the bolt of the negative terminal of the battery, jack up the front of the car and remove the electrical connector from the CKP sensor. These are removed by using nut/bolt that are found on top of the mounting rails and this process involves detaching and physically pulling out the sensor note that the process of installing is done by reversing the removal process. In the 4.6L V8 engine, the CKP sensor is mounted with its connector at the right frontal corner of the engine block which means that the air conditioning compressor must be removed to access the sensor. The negative terminal of the battery must be disconnected, the drivebelt removed and the front of the vehicle raised. Unplug the wiring harness clips from the air conditioning compressor and remove the electrical connector from the compressor clutch, accompanied by removal of the air conditioning compressor screws that do not involve disconnecting of the refrigerant lines. Loosen the electrical connector of the CKP sensor, unbolt and extract the sensor. Installation is done in the reverse sequence. Like in the 5.0L V8, the CKP sensor is located at the back side of the engine block between the engine block and bell housing. Remove the negative terminal from the battery, then the electrical connector from CKP sensor. After that, you have to take out the mounting bolt and to pull the sensor through the rear oil seal retainer and the engine block boss. Put a few drops of clean engine oil on the O-ring of the sensor and bring the sensor in sitting position securely and tighten the nut using the retaining bolt care should be taken for not damaging the gasket if it is not placed fully seated. The rest of installation is the reverse of removal.

Genuine Ford Mustang Crankshaft Position Sensor

Engine Crankshaft Position Sensor

Select Vehicle by Model
Select Vehicle by VIN

Select Vehicle by Model

Make

Model

Year

Select Vehicle by VIN

For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).

11 Crankshaft Position Sensors found

View related parts
Ford Mustang Sensor - Crankshaft Position
Part Number: 1W7Z-6C315-AB
$40.13 MSRP: $64.00
You Save: $23.87 (38%)
Ships in 1 Business Day
ADD TO CART
Product Specifications
- Other Name: Sensor - Crankshaft Position - Cps
- Manufacturer Note: Sensor asy. (Crankshaft position) #1W7E 6C315-AA
- Replaces: 1W7Z-6C315-AA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2001-2014 Ford Mustang | 8 Cyl 4.6L DOHC EFI, 8 Cyl 4.6L DOHC EFI S/C, 8 Cyl 4.6L SOHC EFI, 8 Cyl 5.4L DOHC EFI S/C ALUM, 8 Cyl 5.8L DOHC SC | 4AT 4R75W, 4-Speed Automatic Transmission 4R70W (AODE), 5-Speed Automatic Transmission 5R55S, 5-Speed Manual Transmission (T450D), 5-Speed Manual Transmission T5OD, 5-Speed Manual Transmission TR3650, 6-Speed Automatic Transmission (6R80), 6-Speed Manual Transmission (T56), 6-Speed Manual Transmission Tremec T56, 6-Speed Manual Transmission-MT82, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Mustang Sensor - Crankshaft Position
Part Number: AA5Z-6C315-A
$45.71 MSRP: $72.91
You Save: $27.20 (38%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor - Crankshaft Position - Cps; Crankshaft Position Sensor, Crankshaft Sensor
- Manufacturer Note: Includes Attaching Bolt
- Replaces: AT4Z-6C315-A, 7T4Z-6C315-B
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2011-2019 Ford Mustang | 6 Cyl 3.7L PFI NA | 10-Speed Automatic Transmission (10R80), 6-Speed Automatic Transmission (6R80), 6-Speed Manual Transmission (T56), 6-Speed Manual Transmission-3160, 6-Speed Manual Transmission-MT82, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Mustang Sensor - Crankshaft Position
Part Number: 5L2Z-6C315-A
$38.51 MSRP: $60.36
You Save: $21.85 (37%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor - Crankshaft Position - Cps
- Replaces: 1L2Z-6C315-BB
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2005-2010 Ford Mustang | 6 Cyl 4.0L SOHC EFI | 5-Speed Automatic Transmission 5R55S, 5-Speed Manual Transmission T5OD, 5-Speed Manual Transmission TR3650, 6-Speed Manual Transmission (T56), Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Mustang Sensor - Crankshaft Position
Part Number: 6M8Z-6C315-AA
$70.79 MSRP: $112.91
You Save: $42.12 (38%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor - Crankshaft Position - Cps
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2015-2023 Ford Mustang | 4 Cyl 2.3 L GAS, 4 Cyl 2.3L TIVCT DI TC | 10-Speed Automatic Transmission (10R80), 6-Speed Automatic Transmission (6R80), 6-Speed Manual Transmission-3160, 6-Speed Manual Transmission-MT82, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Mustang Sensor - Crankshaft Position
Part Number: JR3Z-6C315-A
$39.10 MSRP: $62.36
You Save: $23.26 (38%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor - Crankshaft Position - Cps; Crankshaft Position Sensor, Crankshaft Sensor
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2018-2024 Ford Mustang | 4 Cyl 2.3 L GAS, 8 Cyl 5.0 L GAS, 8 Cyl 5.0L DOHC EFI Modular, 8 Cyl 5.0L MOD DOHC SEFI NA, 8 Cyl 5.2 L GAS | 10-Speed Automatic Transmission (10R80), 6-Speed Manual Transmission-3160, 6-Speed Manual Transmission-MT82, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Mustang Sensor - Crankshaft
Part Number: BR3Z-6C315-A
$37.28 MSRP: $59.45
You Save: $22.17 (38%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor - Crankshaft Position - Cps
- Replaced by: BR3Z-6C315-B
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2011-2017 Ford Mustang | 8 Cyl 5.0L DOHC EFI Modular, 8 Cyl 5.0L MOD DOHC SEFI NA | 6-Speed Automatic Transmission (6R80), 6-Speed Manual Transmission (T56), 6-Speed Manual Transmission-3160, 6-Speed Manual Transmission-MT82, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Mustang Sensor - Crankshaft Position - CPS
Part Number: 1F2Z-6C315-AA
$33.29 MSRP: $53.09
You Save: $19.80 (38%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Replaced by: 4F2Z-6C315-BA
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2001-2004 Ford Mustang | 6 Cyl 3.8L OHV EFI, 6 Cyl 3.9L OHV EFI NA | 4AT 4R75W, 4-Speed Automatic Transmission 4R70W (AODE), 5-Speed Manual Transmission (T450D), 5-Speed Manual Transmission T5OD, 5-Speed Manual Transmission TR3650, 6-Speed Manual Transmission Tremec T56, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Mustang Sensor - Crankshaft Position - CPS
Part Number: 1L2Z-6C315-BB
$38.51 MSRP: $60.36
You Save: $21.85 (37%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Replaced by: 5L2Z-6C315-A
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2005 Ford Mustang | 6 Cyl 4.0L SOHC EFI | 5-Speed Automatic Transmission 5R55S, 5-Speed Manual Transmission T5OD, 5-Speed Manual Transmission TR3650, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Mustang Sensor - Crankshaft Position
Part Number: BR3Z-6C315-C
$37.58 MSRP: $58.91
You Save: $21.33 (37%)
Ships in 1-3 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor - Crankshaft Position - Cps; Crankshaft Position Sensor, Crankshaft Sensor
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2015-2022 Ford Mustang | 8 Cyl 5.2 L GAS, 8 Cyl 5.2L | 10-Speed Automatic Transmission (10R80), 6-Speed Automatic Transmission (6R80), 6-Speed Manual Transmission-3160, 6-Speed Manual Transmission-MT82, Left Hand Drive, Rear-Wheel Drive (Left Hand Drive)
View related parts
Ford Mustang SENSOR - CRANKSHAFT POSITION
Part Number: P2GZ-6C315-B
$9.57 MSRP: $14.87
You Save: $5.30 (36%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Crankshaft Position Sensor, Crankshaft Sensor
- Replaces: P2GZ-6C315-A
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 2024 Ford Mustang | 4 Cyl 2.3 L GAS
View related parts
Ford Mustang Sensor Crankshaft Position
Part Number: EOAZ6C315A
$72.42 MSRP: $100.60
You Save: $28.18 (29%)
Ships in 1-2 Business Days
ADD TO CART
Product Specifications
- Other Name: Sensor - Crankshaft Position - Cps; Crankshaft Position Sensor
- Warranty: This genuine part is guaranteed by Ford's factory warranty.
Fits the following Vehicles:
- 1983-1984 Ford Mustang | 6 Cyl 3.8L | 3AT C3, 3AT C5, 4AT AOD, 4MT, 5MT

Ford Mustang Crankshaft Position Sensor

Crankshaft Position Sensor is an electronic device used in Ford Mustang cars' that is used to detect crankshaft position and its revolutions per minute. This sensor sends vital information to the powertrain control module through which powertrain can know the exact time to ignite fuel with optimal conditions and amount of fuel to be injected to the engine for it to perform to the optimal of its capacity. There are several varieties of Crankshaft Position Sensors that Ford Mustang has used over the years these include the inductive, Hall Effect, magnetoresistive, and optical. Inductive sensors are of the indirect contact type and are non-active while Hall Effect and magnetoresistive sensors are able to detect static magnetic fields. Optical sensors give precise recognition of the edges but have the problem of fouling. The most significant differences between these sensor types are related to their operating principles as well as their sensitivity to certain conditions. Problems with Crankshaft Position Sensor may cause cranking or performance concerns thus enshrouding its relevance among the Ford Mustang models.

We provide a wide range of Ford Mustang Crankshaft Position Sensor at the best prices possible. If you need Ford Mustang Crankshaft Position Sensor, you can shop with confidence on our website. All our OEM parts come with a manufacturer's warranty and are delivered to your door step with a fast delivery service.

Ford Mustang Crankshaft Position Sensor Parts Questions & Experts Answers

Sensor - Crankshaft Position - CPS
1L2Z-6C315-BB
Q: How to replace the CKP sensor on Ford Mustang?
A: A CKP sensor for the 3.7L V6 engine is situated at the rear of the engine block at an opening on the side of the engine. First, remove the cable involving the negative terminal of the battery, then follow the correct procedure that is the raising of the automobile off the ground with the aid of jacks and placement of jackstands. Remove heat shield fasteners; heat shield then rubber grommet/plug from the left side of the engine block. Open the access hole to quickly unplug the electrical connector from CKP sensor, and then the center bolt can be removed to take the sensor out of the rear oil seal retainer. Coat the O-ring for the sensor with the clean engine oil, insert the sensor to the seal retainer until it is hidden and lock it with the mounting bolt. For the 4.0L V6 engine, the CKP sensor is installed on the front side of the timing chain cover . Remove the bolt of the negative terminal of the battery, jack up the front of the car and remove the electrical connector from the CKP sensor. These are removed by using nut/bolt that are found on top of the mounting rails and this process involves detaching and physically pulling out the sensor note that the process of installing is done by reversing the removal process. In the 4.6L V8 engine, the CKP sensor is mounted with its connector at the right frontal corner of the engine block which means that the air conditioning compressor must be removed to access the sensor. The negative terminal of the battery must be disconnected, the drivebelt removed and the front of the vehicle raised. Unplug the wiring harness clips from the air conditioning compressor and remove the electrical connector from the compressor clutch, accompanied by removal of the air conditioning compressor screws that do not involve disconnecting of the refrigerant lines. Loosen the electrical connector of the CKP sensor, unbolt and extract the sensor. Installation is done in the reverse sequence. Like in the 5.0L V8, the CKP sensor is located at the back side of the engine block between the engine block and bell housing. Remove the negative terminal from the battery, then the electrical connector from CKP sensor. After that, you have to take out the mounting bolt and to pull the sensor through the rear oil seal retainer and the engine block boss. Put a few drops of clean engine oil on the O-ring of the sensor and bring the sensor in sitting position securely and tighten the nut using the retaining bolt care should be taken for not damaging the gasket if it is not placed fully seated. The rest of installation is the reverse of removal.
