Cylinder Block & Related Parts fit your 1997 Ford Taurus 6 Cyl 3.0L 4-Speed Automatic Transmission AX4N

24V , M12 thread-Rubber coated flanged head -Also incl. in 6675 asy.

Service plug may differ from original, Flex Fuel-(Methanol/Ethanol)

Located between the EGR valve and the 9D477 EGR tube, 4V

#F77F 10884-AA; 2 spade terminal connector, 3/8"-18 PTF SAE.
#F77F-10884-AB, 2 spade connector, 3.0L, 3.4L, DOHC

24V , Bolt; M10x106mm; Main caps to Cyl. Block, Positions 9,10,11,12,13,14,15,16

24V , Bolt-M8 x 94 mm-Bulk Head to Cyl. Block, Positions 2,3,4,17

24V , Bolt; M8 x 51mm, Attaches front cover to block; Positions 4, 10, 13, 14, 15 & 16

12V , Stud; M8 x 43.5; Attaches front cover to block

12V , Stud; M8x53mm; attaches front cover to block., exc. SHO

12V , Stud; M6 x 28.5; attaches Water pump & front cover to block.

24V , M8x34, Bolt; Attaches front cover to block; Positions 7 & 9

24V , M8x68mm x M8x28, Stud; Attaches front cover to block; Positions 2, 3, 5, 6, 8, 11 & 12

12V , Exhaust-Std.-Use w/ 8mm O/D valves, exc. SHO, BEFORE 7/27/99

12V , Incl. F & L conn. & valve-Discard connectors if not used., FROM 11/1/95

12V , Cup- 1.50"/.38.30mm OD -core holes in block, exc. SHO

1/2 x 14 mm pipe-RH and Center rear of Cyl. Block , 24V

12V , Round insulator, forward of the rear wheels (insulator also serviced together with the bracket in the F2DZ 5277-A and YF1Z 5277-AA assemblies)

12V , Bracket and round insulator, forward of the rear wheels (insulator also serviced separately as F2OY 5F262-A)

12V , Bracket and round insulator, forward of the rear wheels (insulator also serviced separately as F2OY 5F262-A)

12V , Pre-converter and pipe asy, LH, flex fuel methanol

12V , ID: "BOR". See OASIS or TSB 02-21-08 for repair procedures for cracks at the NVH bracket on 1997/1999 E/ME vehicles. Do not replace the catalyst assembly for a crack in this area to which the TSB can be used for repair, 12 valve, flex fuel (methenol), AX4S, 49 States (Federal) & Canadian requirements

12V , ID "MIK". See OASIS or TSB 02-21-08 for repair procedures for cracks at the NVH bracket on 1997/1999 E/ME vehicles. Do not replace the catalyst assembly for a crack in this area to which the TSB can be used for repair., 12 valve, flex fuel (ethanol), AX4S, 49 States (Federal) & Canadian requirements

12V , Insulator - Clover-leafed shaped, also Serviced together with the bracket in the 5D203 or 5D204 assembly.

12V , ID "LEV". See OASIS or TSB 02-21-08 for repair procedures for cracks at the NVH bracket on 1997/1999 E/ME vehicles. Do not replace the catalyst assembly for a crack in this area to which the TSB can be used for repair., AX4S, 12 valve, California, New York & green state emissions, with a 4 1/2" neck

12V , ID "GIB". See OASIS or TSB 02-21-08 for repair procedures for cracks at the NVH bracket on 1997/1999 E/ME vehicles. Do not replace the catalyst assembly for a crack in this area to which the TSB can be used for repair., 12 valve, unleaded fuel, AX4S, 49 States (Federal) & Canadian requirements, with a 1 3/4" neck, FROM 3/05/97

12V , ID "GUP". See OASIS or TSB 02-21-08 for repair procedures for cracks at the NVH bracket on 1997/1999 E/ME vehicles. Do not replace the catalyst assembly for a crack in this area to which the TSB can be used for repair., 12 valve, unleaded fuel, AX4N, 49 States (Federal) & Canadian requirements, with a 1 3/4" neck, FROM 2/22/97

(AW-70-A) STUD (ATT. MANIFOLD TO HEAD) M8 X 1.25 X 69.25 HEX SHOULDER

(AB-116-GB) SCREW (ATT. MANIFOLD TO HEAD) M8 X 1.25 X 45.5 HEX HEAD

Stud (AW-43-S) - attaches 5F250 to manifold, M10 x 1.5 x 1.5 x 73.5

RH, use N807040,S2 to cap EGR hole , 2V, w/Flex Fuel (Methanol/ Gasoline) and with Calif. Ems., Canada

LH, 2V, w/o Flex Fuel (Ethanol/Gasoline)
LH, RFF6DE-9431-EB, 2V, w/Flex Fuel (Ethanol/Gasoline) and without Calif. Ems.

LH, #RFF6DE,9431,HE , 2V, w/Flex Fuel (Methanol/ Gasoline) and with Calif. Ems., Canada

12V , Replaced by complete timing gear set 6B290, 5/8" wide chain

12V , Use with 8mm O/D valves, exc. SHO, BEFORE 7/27/99

M20 one end and M22 the other. , OHV; W/ Calif. Ems.

5.1,6.1mm ID, 215mm long. May need cut to length , 2V

Complete serv only kit-upper & lower bearing-.25mm/.010" U/S

Complete serv only kit-upper & lower bearing-.50mm/.020" U/S

24V , Complete serv only kit-upper & lower bearing-Std

24V , Complete serv only kit,upper & lower bearing,.50mm/.020" U/S

24V , Complete serv only kit,upper & lower bearing,.25mm/.010 U/S
